最近需要生成一个动态的验证码，在登录页面使用，并在前后端进行校验；
实现原理：
后端生成动态二维码，存储在 session 里面；
前端调取接口，展示在登录页面；
前端登录时候，把验证码传给后端，后端和 session 里面的值进行对比。
1 生成动态验证码图片
新建一个 class类 ValidateCode:
package hello;
import org.apache.commons.io.FileUtils;
import javax.imageio.ImageIO;
import javax.servlet.http.HttpServletRequest; import javax.servlet.http.HttpServletResponse; import javax.servlet.http.HttpSession; import java.awt.*; import java.awt.image.BufferedImage; import java.io.ByteArrayOutputStream; import java.io.IOException; import java.util.Base64; import java.util.HashMap; import java.util.Map; import java.util.Random; // 生成随机验证码 public class ValidateCode { private static Random random = new Random(); private int width = 160;// 宽 private int height = 40;// 高 private int lineSize = 30;// 干扰线数量 private int stringNum = 4;//随机产生字符的个数 private String randomString = "0123456789abcdefghijklmnopqrstuvwxyz"; private final String sessionKey = "RANDOMKEY"; /* * 获取字体 */ private Font getFont() { return new Font("Times New Roman", Font.ROMAN_BASELINE, 40); } /* * 获取颜色 */ private static Color getRandomColor(int fc, int bc) { fc = Math.min(fc, 255); bc = Math.min(bc, 255); int r = fc + random.nextInt(bc - fc - 16); int g = fc + random.nextInt(bc - fc - 14); int b = fc + random.nextInt(bc - fc - 12); return new Color(r, g, b); } /* * 绘制干扰线 */ private void drawLine(Graphics g) { int x = random.nextInt(width); int y = random.nextInt(height); int xl = random.nextInt(20); int yl = random.nextInt(10); g.drawLine(x, y, x + xl, y + yl); } /* * 获取随机字符 */ private String getRandomString(int num) { num = num > 0 ? num : randomString.length(); return String.valueOf(randomString.charAt(random.nextInt(num))); } /* * 绘制字符串 */ private String drawString(Graphics g, String randomStr, int i) { g.setFont(getFont()); g.setColor(getRandomColor(108, 190)); System.out.println(random.nextInt(randomString.length())); String rand = getRandomString(random.nextInt(randomString.length())); randomStr += rand; g.translate(random.nextInt(3), random.nextInt(6)); g.drawString(rand, 40 * i + 10, 25); return randomStr; } /* * 生成随机图片 */ public void getRandomCodeImage(HttpServletRequest request, HttpServletResponse response) { HttpSession session = request.getSession(); // BufferedImage类是具有缓冲区的Image类,Image类是用于描述图像信息的类 BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_BGR); Graphics g = image.getGraphics(); g.fillRect(0, 0, width, height); g.setColor(getRandomColor(105, 189)); g.setFont(getFont()); // 绘制干扰线 for (int i = 0; i < lineSize; i++) { drawLine(g); } // 绘制随机字符 String random_string = ""; for (int i = 0; i < stringNum; i++) { random_string = drawString(g, random_string, i); } System.out.println(random_string); g.dispose(); session.removeAttribute(sessionKey); session.setAttribute(sessionKey, random_string); String base64String = ""; try { // 直接返回图片 ImageIO.write(image, "PNG", response.getOutputStream()); } catch (Exception e) { e.printStackTrace(); } } }
接下来写个 Controller , 提供个接口给前端：
package hello;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.bind.annotation.RestController;
import javax.servlet.http.HttpServletRequest; import javax.servlet.http.HttpServletResponse; import java.util.HashMap; import java.util.Map; @RestController @RequestMapping("/api/v1/user") public class ValidateCodeController { // 生成验证码图片 @RequestMapping("/getCaptchaImage") @ResponseBody public void getCaptcha(HttpServletRequest request, HttpServletResponse response) { try { response.setContentType("image/png"); response.setHeader("Cache-Control", "no-cache"); response.setHeader("Expire", "0"); response.setHeader("Pragma", "no-cache"); ValidateCode validateCode = new ValidateCode(); // 直接返回图片 validateCode.getRandomCodeImage(request, response); } catch (Exception e) { System.out.println(e); } } }
2 前端调取接口
结果如图：
3 返回 base64 字符串
有时候我们不能直接返回图片，需要返回一个 json 的数据比如：
这时候我们就需要把 image 转化为 base64；
具体代码如下：
在之前的 ValidateCode 类中添加一个方法：
/*
* 生成随机图片，返回 base64 字符串
*/
public String getRandomCodeBase64(HttpServletRequest request, HttpServletResponse response) {
HttpSession session = request.getSession();
// BufferedImage类是具有缓冲区的Image类,Image类是用于描述图像信息的类 BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_BGR); Graphics g = image.getGraphics(); g.fillRect(0, 0, width, height); g.setColor(getRandomColor(105, 189)); g.setFont(getFont()); // 绘制干扰线 for (int i = 0; i < lineSize; i++) { drawLine(g); } // 绘制随机字符 String random_string = ""; for (int i = 0; i < stringNum; i++) { random_string = drawString(g, random_string, i); } System.out.println(random_string); g.dispose(); session.removeAttribute(sessionKey); session.setAttribute(sessionKey, random_string); String base64String = ""; try { // 直接返回图片 // ImageIO.write(image, "PNG", response.getOutputStream()); //返回 base64 ByteArrayOutputStream bos = new ByteArrayOutputStream(); ImageIO.write(image, "PNG", bos); byte[] bytes = bos.toByteArray(); Base64.Encoder encoder = Base64.getEncoder(); base64String = encoder.encodeToString(bytes); } catch (Exception e) { e.printStackTrace(); } return base64String; }
在 Controller 添加另外一个路由接口：
// 生成验证码,返回的是 base64
@RequestMapping("/getCaptchaBase64")
@ResponseBody
public Object getCaptchaBase64(HttpServletRequest request, HttpServletResponse response) {
调用结果：
在前端页面中，只要把 URL 放到 image 的 URL 中，即可显示，这里不再演示。
3 验证验证码
生成：
验证：
