最近需要生成一个动态的验证码，在登录页面使用，并在前后端进行校验；
实现原理：
后端生成动态二维码，存储在 session 里面；
前端调取接口，展示在登录页面；
前端登录时候，把验证码传给后端，后端和 session 里面的值进行对比。
1 生成动态验证码图片
新建一个 class类 ValidateCode:
package hello;
import org.apache.commons.io.FileUtils;
import javax.imageio.ImageIO;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import javax.servlet.http.HttpSession;
import java.awt.*;
import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.util.Base64;
import java.util.HashMap;
import java.util.Map;
import java.util.Random;
// 生成随机验证码
public class ValidateCode {
private static Random random = new Random();
private int width = 160;// 宽
private int height = 40;// 高
private int lineSize = 30;// 干扰线数量
private int stringNum = 4;//随机产生字符的个数
private String randomString = "0123456789abcdefghijklmnopqrstuvwxyz";
private final String sessionKey = "RANDOMKEY";
/*
* 获取字体
*/
private Font getFont() {
return new Font("Times New Roman", Font.ROMAN_BASELINE, 40);
}
/*
* 获取颜色
*/
private static Color getRandomColor(int fc, int bc) {
fc = Math.min(fc, 255);
bc = Math.min(bc, 255);
int r = fc + random.nextInt(bc - fc - 16);
int g = fc + random.nextInt(bc - fc - 14);
int b = fc + random.nextInt(bc - fc - 12);
return new Color(r, g, b);
}
/*
* 绘制干扰线
*/
private void drawLine(Graphics g) {
int x = random.nextInt(width);
int y = random.nextInt(height);
int xl = random.nextInt(20);
int yl = random.nextInt(10);
g.drawLine(x, y, x + xl, y + yl);
}
/*
* 获取随机字符
*/
private String getRandomString(int num) {
num = num > 0 ? num : randomString.length();
return String.valueOf(randomString.charAt(random.nextInt(num)));
}
/*
* 绘制字符串
*/
private String drawString(Graphics g, String randomStr, int i) {
g.setFont(getFont());
g.setColor(getRandomColor(108, 190));
System.out.println(random.nextInt(randomString.length()));
String rand = getRandomString(random.nextInt(randomString.length()));
randomStr += rand;
g.translate(random.nextInt(3), random.nextInt(6));
g.drawString(rand, 40 * i + 10, 25);
return randomStr;
}
/*
* 生成随机图片
*/
public void getRandomCodeImage(HttpServletRequest request, HttpServletResponse response) {
HttpSession session = request.getSession();
// BufferedImage类是具有缓冲区的Image类,Image类是用于描述图像信息的类
BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_BGR);
Graphics g = image.getGraphics();
g.fillRect(0, 0, width, height);
g.setColor(getRandomColor(105, 189));
g.setFont(getFont());
// 绘制干扰线
for (int i = 0; i < lineSize; i++) {
drawLine(g);
}
// 绘制随机字符
String random_string = "";
for (int i = 0; i < stringNum; i++) {
random_string = drawString(g, random_string, i);
}
System.out.println(random_string);
g.dispose();
session.removeAttribute(sessionKey);
session.setAttribute(sessionKey, random_string);
String base64String = "";
try {
// 直接返回图片
ImageIO.write(image, "PNG", response.getOutputStream());
} catch (Exception e) {
e.printStackTrace();
}
}
}
接下来写个 Controller , 提供个接口给前端：
package hello;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.bind.annotation.RestController;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.util.HashMap;
import java.util.Map;
@RestController
@RequestMapping("/api/v1/user")
public class ValidateCodeController {
// 生成验证码图片
@RequestMapping("/getCaptchaImage")
@ResponseBody
public void getCaptcha(HttpServletRequest request, HttpServletResponse response) {
try {
response.setContentType("image/png");
response.setHeader("Cache-Control", "no-cache");
response.setHeader("Expire", "0");
response.setHeader("Pragma", "no-cache");
ValidateCode validateCode = new ValidateCode();
// 直接返回图片
validateCode.getRandomCodeImage(request, response);
} catch (Exception e) {
System.out.println(e);
}
}
}
2 前端调取接口
结果如图：
3 返回 base64 字符串
有时候我们不能直接返回图片，需要返回一个 json 的数据比如：
这时候我们就需要把 image 转化为 base64；
具体代码如下：
在之前的 ValidateCode 类中添加一个方法：
/*
* 生成随机图片，返回 base64 字符串
*/
public String getRandomCodeBase64(HttpServletRequest request, HttpServletResponse response) {
HttpSession session = request.getSession();
// BufferedImage类是具有缓冲区的Image类,Image类是用于描述图像信息的类
BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_BGR);
Graphics g = image.getGraphics();
g.fillRect(0, 0, width, height);
g.setColor(getRandomColor(105, 189));
g.setFont(getFont());
// 绘制干扰线
for (int i = 0; i < lineSize; i++) {
drawLine(g);
}
// 绘制随机字符
String random_string = "";
for (int i = 0; i < stringNum; i++) {
random_string = drawString(g, random_string, i);
}
System.out.println(random_string);
g.dispose();
session.removeAttribute(sessionKey);
session.setAttribute(sessionKey, random_string);
String base64String = "";
try {
// 直接返回图片
// ImageIO.write(image, "PNG", response.getOutputStream());
//返回 base64
ByteArrayOutputStream bos = new ByteArrayOutputStream();
ImageIO.write(image, "PNG", bos);
byte[] bytes = bos.toByteArray();
Base64.Encoder encoder = Base64.getEncoder();
base64String = encoder.encodeToString(bytes);
} catch (Exception e) {
e.printStackTrace();
}
return base64String;
}
在 Controller 添加另外一个路由接口：
// 生成验证码,返回的是 base64
@RequestMapping("/getCaptchaBase64")
@ResponseBody
public Object getCaptchaBase64(HttpServletRequest request, HttpServletResponse response) {
Map result = new HashMap();
Response response1 = new Response();
try {
response.setContentType("image/png");
response.setHeader("Cache-Control", "no-cache");
response.setHeader("Expire", "0");
response.setHeader("Pragma", "no-cache");
ValidateCode validateCode = new ValidateCode();
// 直接返回图片
// validateCode.getRandomCode(request, response);
// 返回base64
String base64String = validateCode.getRandomCodeBase64(request, response);
result.put("message", "created successfull");
System.out.println("test=" + result.get("url"));
response1.setData(0, result);
} catch (Exception e) {
System.out.println(e);
}
return response1.getResult();
}
调用结果：
在前端页面中，只要把 URL 放到 image 的 URL 中，即可显示，这里不再演示。
3 验证验证码
生成：
验证：
